Kverneland iXtra
Zarządzanie zbiornikami - elastyczność podczas oprysku.
Innowacyjny zbiornik czołowy Kverneland iXtra Comfort lub Pro oferuje znacznie więcej niż tylko dodatkową pojemność zbiornika. W połączeniu z opryskiwaczem zawieszanym iXter B, iXtra zapewnia całkowitą objętość około 3000 litrów, co czyni kombinację iXter-iXtra realną alternatywą dla opryskiwacza samojezdnego.
Opis
W sytuacji, gdy ciągniki mogą przenosić duże obciążenia na tylnych podnośnikach, potrzeba balastu z przodu ciągnika jest niezbędna. Przy nominalnej pojemności 1100 litrów, przedni zbiornik iXtra pełni rolę obciążnika dodającego stabilności ciągnikowi, ale tylko wtedy gdy jest to potrzebne! Zarządzanie zbiornikami iXter-iXtra pozwala na podejście jednozbiornikowe, w którym oba zbiorniki są wypełnione cieczą roboczą lub podejście dwuzbiornikowe z dwoma różnymi mieszaninami, ponieważ zbiornik przedni i tylny mogą być używane jako dwa niezależne zbiorniki opryskiwacza. Alternatywnie, zbiornik przedni iXtra może być napełniony czystą wodą lub skoncentrowanym środkiem, ponieważ może być wykorzystany jako zbiornik rezerwowy do późniejszego użycia na innym polu lub w innej uprawie.
Cechy
The Multi-tank-managment strategy with independent filling offers you the possibility to work with two separate spray tanks or cleverly, as one large sprayer with automatic balancing of tank contents. If needed, spray liquid can be transferred in both directions.
The iXtra concept with combined functions gives you more flexibility while spraying:
- One-tank approach: both tanks are filled with spray liquid it boosts overall tank capacity by 60% (automatic level system)
- Two-tank approach: filled with two different tank mixes, the front and rear tanks can be used as two independent spray tanks
- Reservoir approach: filled with clean water or a concentrated product the iXtra front tank can be used as a reservoir for later use, for example in another field or crop.
Fully Integrated Design
The iXtra offers you a completely integrated concept. The two clean water tanks with level indicators are part of the design, as well as the quick hitch system and control panel.
Easy Set Control Panel
The valve panel on the front tank is used for draining, agitation and cleaning. An electric pump guarantees mixing and cleaning, independently from the rear sprayer. You can select the front tank from the cab or throught the Easy Set valve panel on the iXter B sprayer.
Easy to Fit, Simple to Unhitch
Without a front PTO shaft or hydraulic hoses, hitching the iXtra is extremely simple: it uses only two hoses with KAMlock connections and an electrical cable - it really is that simple!
Easy Operation
The iXtra front tank uses the functions of the iXter B sprayer when filling and spraying. This avoids the need - or additional cost - for a separate induction hopper or spray pump for the front tank. All the necessary controls are conveniently located on the sprayer and are operated from the Easy Set valve panel on the iXter B.
-
Electrical Level Indicator
The electrical level indicator on the front tank provides actual tank volume to a spraying computer as well as via the external display on the Easy Set control panel of the iXter B mounted sprayer.
-
iXclean Basic
ENFO priming and rinsing is standard on all Kverneland spray computers. Before spraying starts the spray lines are filled with chemicals exactly up to the nozzle by automatic shut off. After finishing or interruption, crop protection agents are automatically flushed out of the spray lines with a minimum of clean water consumption. This ENFO technology optimizes filling and cleaning of the spray lines. Accurate application, no waste of products and saving water are the benefit for the environment.
-
iXclean Comfort
iXclean Comfort is a semi-automatic valve control system. The combination of an electrical level indicator and suction valve provides operator comfort and accuracy; automatic filling stops when the programmed level is reached, and remote control of all ENFO rinising and priming functions are carried out from the cab! Simple prime the spray lines before you start and rinse them afterwards.
-
iXclean Pro
iXclean Pro is an advanced solution with fully automatic, electric valve management. It means all functions can be controlled from the cab. Switching between filling, agitation, spraying, diluting, priming, rinsing and tank cleaning, is extremely easy: just push the button! In addition iXclean Pro offers also a fully automatic multi-step rinsing and cleaning program with triple dilution for the entire sprayer. Pushing one button a comprehensive cleaning process including all lines will start. It is so thorough, that residue levels after automated cleaning are below 1%.
-
iXflow-E
iXflow-E is the high pressure recirculation system with electric nozzle control. There is a free circulation of chemicals with a return of spray liquid back to the tank as spraying stops. This means there is no sedimentation in the spray lines and no dead ends for spraying or cleaning, even when the boom is in vertical position. During spraying each section gets under pressure from both ends of the spray lines, so the operator can immediately start spraying without any pressure drop. It is easy for the operator to program the number and size of sections which fits the best to their requirements and field situations.
Rolnictwo precyzyjne
When deciding what equipment to purchase, it is not always easy to find the optimal solution in the broad market offering of today. Technology is developing fast and tractors and implements are more and more equipped with high tech electronics. We understand this complexity and are committed to provide you with easy farming solutions. Therefore these cost-efficient ISOBUS Universal Terminals, IsoMatch Tellus PRO and IsoMatch Tellus GO+ are made for easy machine control and efficient farming.
With its advanced hardware and software features, the IsoMatch Tellus PRO provides the optimal precision farming solution for an all-in-one control system inside your tractor cab.
IsoMatch Tellus PRO is the centre for connecting all ISOBUS machines and a platform for running precision farming applications. It offers everything a farmer needs to get the maximum out of his machines and crops, as well as cost savings in fertiliser, chemicals and seeds by using automatic section control and variable rate control. With the unique dual screen functionality it gives the farmer the opportunity to view and control two machines and processes simultaneously.
Work easy. Be in control.
IsoMatch Tellus GO+ is especially developed for controlling the machine in a simple way. The farmer is in full control of the machine in exactly the way he wants. Easy set up the machine with the soft keys via the 7-inch touch screen. And, optimal control while driving, just use the hard keys and rotary switch. Controlling the implement has never been so easy.
This can be you your first step into Precision Farming
IsoMatch Tellus GO+ makes it easy to control any ISOBUS machine from your tractor cab. IsoMatch GEOCONTROL enables you to achieve higher yields, lower costs and do your work with less hassle. This licence key is divided in two parts, Section Control and Variable Rate Control, which are available from the IsoMatch Shop. Now you can buy the specific functionality that you need.
With manual guidance you are perfectly on track.
The IsoMatch InLine is a light bar which allows easy manual guidance. It is the perfect assistant to get you as close as possible to your desired A-B line. Mounted in the line of sight, you can easily see the distance from the A-B line and to which direction you should steer for the ideal position. The display of the IsoMatch InLine also displays the status of the machine sections, which adds more comfort of use. The LEDs can be dimmed for night operation.
SMART
Distance to A-B line with LED indication and a numeric display
EFFICIENT
Manual guidance in combination with IsoMatch GEOCONTROL
EASY
Displays status of machine sections
The essential accessory for IsoMatch GEOCONTROL.
The IsoMatch Global 3 is the GPS antenna, with DGPS accuracy, in the IsoMatch product range. It enables satellite navigation for site-specific section control, variable rate application, manual guidance and field registration.
SMART
Allows manual guidance, automatic section control and variable rate in combination with IsoMatch GEOCONTROL
EFFICIENT
DGPS accuracy without additional subscription fees
EASY
Easy to fit with mounting brackets included
Made for smart, efficient and easy farming
IsoMatch GEOCONTROL is an advanced software application within the IsoMatch Tellus PRO and IsoMatch Tellus GO+ that helps you to control all ISOBUS compatible Kverneland Group machines such as sprayers, spreaders and seeders! Combined with a GPS receiver it fulfils the future needs in terms of easy, smart and efficient farming!
IsoMatch MultiEye is an accessory for connecting multiple cameras to the IsoMatch Universal Terminal.
With the IsoMatch MultiEye you can connect multiple cameras to the IsoMatch Tellus PRO or IsoMatch Tellus GO+ Terminal. You can easily switch between the cameras without the need for an additional screen in you tractor cabin. It gives you full control and overview of the entire machine operation during day and night, because of its night vision by integrated LED’s. This increases the safety when reversing the machine or manoeuvring around obstructions.
SMART
You can connect up to four IsoMatch Eye cameras and easily switch between the cameras with the remote control box which is standard included.
EFFICIENT
Full control and overview of entire machine operation from every side you want.
EASY
Night vision by integrated LED’s which increases the safety when reversing the machine or manoeuvring around obstructions.
The IsoMatch Grip is an ISOBUS auxiliary device developed for great operator comfort and efficient machine control. Its ergonomic shape and the complete freedom of assigning and controlling a total of 44 implement functions from one device are unique in the market today. From your fingertips you have endless possibilities to operate all machine functions as desired. And assignments are saved per machine making it even more applicable to your needs.
Connect to a local wireless network on your IsoMatch Tellus.
IsoMatch Wireless (USB-stick) is complementary to the IsoMatch Tellus and makes it easy to connect to a local wireless network, such as your phone’s hot-spot, home network etc.
No additional costs of an internet service provider. When connected via the IsoMatch Wireless you can browse the internet, view the weather, Gmail, Google, etc.
The IsoMatch Eye is the camera option in the IsoMatch product range.
IsoMatch Eye is a camera that has been developed for use with our sophisticated IsoMatch Tellus GO+ and IsoMatch Tellus PRO dual screen terminal. The IsoMatch Eye is switchable from rear view to standard view.
It gives you full control and overview of entire machine operation during day and night, because of its night vision by integrated LED’s. This increases the safety e.g. when reversing the machine or manoeuvring around obstructions.
SMART
Changeable from rear view to standard view
EFFICIENT
Full control and overview of entire machine operation
EASY
Night vision by integrated LED’s
Specyfikacja techniczna
Specyfikacja techniczna
Pobierz prospekt| iXtra Comfort | iXtra Pro | ||
|---|---|---|---|
| Nominalna pojemność zbiornika (l) | 1100 | 1100 | |
| Maksymalna pojemność zbiornika (l) | 1200 | 1200 | |
| Zbiornik czystej wody (l) | 2x65 | 2x65 | |
| Masa własna (kg) | 221 | 223 | |
| Przedni podnośnik | Cat. II | Cat. II | |
| Wskaźnik poziomu | Mechaniczny | Elektryczny | |
| Panel sterujący | Manualny | Elektryczny (ISOBUS) | |
| iXclean | iXclean Comfort | iXclean Pro | |
| Wydajność pompy elektrycznej 12V (mycie i mieszanie) (l/min) | 25 | 25 |
Specyfikacja techniczna
Specyfikacja techniczna
Pobierz prospektiXtra |
1100 Comfort |
1100 Pro |
Nominal tank capacity |
1100 (l) |
1100 (l) |
Maximum tank capacity |
1300 (l) |
1300 (l) |
Clean water tank capacity |
2 x 65 (l) |
2 x 65 (l) |
Electrical pump capacity |
25 (l/min) |
25 (l/min) |
Empty weight |
221 kg |
223 kg |
Front linkage |
Cat II |
Cat II |
Level Indicator |
Mechanical |
Electrical |
Control panel |
Manual |
Electrical (ISOBUS) |
Regulation systems |
FMC / IsoMatch Tellus PRO / IsoMatch Tellus GO+ |
FMC / IsoMatch Tellus PRO / IsoMatch Tellus GO+ |
iXclean |
iXclean Comfort |
iXclean Comfort / iXclean Pro |
